Hardwood Battery Stations

As low as $1,048.00

Only %1 left

SKU

HBS

Width

Deck Interlay Options

Deck Depth

Remove Charger Shelf

Charger Shelf Placement (leave blank if shelf removed)

Qty

Catalog (PDF)

BHS Hardwood Battery Stations (HBS) are an ideal battery storage solution for BHS Gantry Cranes and other overhead extraction applications. Models are available with a variety of shelf configurations and can be custom-built to your specifications. Drip pans are available for all configurations.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Overview

BHS Hardwood Battery Stations (HBS) are an ideal battery storage solution for BHS Gantry Cranes and other overhead extraction applications. These rugged stations have a heavy-duty frame and a powder-coat finish for added durability.

The station’s recycled polyethylene decking is acid-resistant, nonconductive, and environmentally friendly. A tapered dust rail in the center of the stand prevents accumulation of debris and residue.

Corner-formed Drip Pan Kits are available to catch spilled electrolyte and protect warehouse floors from pitting and corrosion. These custom-fitted pans slide in and out for quick and easy maintenance.

A charger shelf comes standard on all models of the HBS. Anchoring slots fit most models of chargers and Cable Retractor mounting holes aid in cable management.

Models are available with a variety of shelf widths and can be custom-built to your specifications.

Features and Benefits

Heavy duty frame construction for added reliability
Charger shelf standard on all models but can be removed
Decking made of recycled polyethylene is acid resistant, nonconductive and environmentally friendly
Sideways decking orientation available to prevent tipping when using with narrow batteries
Extended deck depth available
12″ (305 mm) standard height from floor to top of plastic interlay
CR-1 Cable Retractor mounting holes
SB connector mounting holes
Charger shelves come slotted allowing for optional 6″ (152 mm) shelf extension between stands
Charger anchoring slots for securing most makes of chargers
Drip pans available
Dust rail constructed at tapered angle in center of stand preventing accumulation of debris
Custom-built models made to your specifications

Specifications

Model	Overall Stand Width
HBS-30	30” (762 mm)
HBS-42	42” (1067 mm)
HBS-60	60” (1524 mm)
HBS-72	72” (1829 mm)
HBS-84	84” (2134 mm)
HBS-96	96” (2438 mm)
HBS-108	108” (2743 mm)
HBS-120	120” (3048 mm)
HBS-144	144” (3658 mm)

Options

Charger Shelf Rearward (HBS-RWD): Increases overhead access to the hardwood deck
Charger Shelf Forward (HBS-FWD): Space saving shelf design for battery rooms where space is limited
Charger Shelf Center (HBS-CTR): Required for 3-ton systems
Drip Pan Kit (DP): Contains spills maintaining a more clean and safe environment
Without Charger Shelf (-1): When ordering, add suffix -1 to model number to indicate HBS without charger shelf
Deck Sideways (-WS): For use with narrow batteries to prevent tipping Note: Add suffix -WS to model number when ordering
Extended Deck Depth (-WS-46): Increases deck depth to 46" (1168 mm) and decking material is installed sideways Note: Add suffix -WS-46 to model number when ordering
