Dockmaster Hydraulic Bin Dumper, 27.5" tip height

For pricing, contact us by calling 314-696-0200 or Request a Quote.

SKU

DM0700

Safely empty roll-out carts and waste bins from docks to dumpsters or hoppers below. The Dockmaster limits tipping height to 27.5” (700 mm) for quick, ergonomic dumping from height, with a maximum weight capacity of up to 550 lbs (250 kg).

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Overview

Create a safer, more efficient loading dock with a dedicated dumping solution. The Dockmaster is designed to empty industrial bins — including roll-out waste carts — from raised platforms to ground-level dumpsters, hoppers, truck beds, and more. Every element of the Dockmaster was designed for safety. Safety bars lock the unit safely into place at dock edges, while a rear-loading door keeps workers safely away from ledges. A unique lift-and-tip action keeps load weights within the frame’s footprint to ensure stability, even while dumping heavy loads. With a lifting capacity of 550 pounds (250 kilograms), the Dockmaster handles heavy industrial materials with ease.

Questions about Simpro Bin Dumpers? Call the Solus Group sales team at 314-696-0200 to learn more.

Features & Benefits

Closed electro-hydraulic systems for virtually maintenance-free operation
Full lifting capacity of 550 lb (250 kg)
Tipping height of 27.5” (700 mm) safely empties from docks to ground level
Safety bars stop the unit from rolling over the dock or platform edges
Standard cradles are compatible with common wheelie bins from 24 to 96 gal (90 to 360 L)
Custom cradles handle specialized containers; contact Solus Group at 314-696-0200 to inquire
Option of battery, solar, 3-phase, or compressed-air power supply; battery-powered units include sealed battery and industrial quality ‘float’ charger.
Duty Cycle: 22,000 lb (1000 kg) of material per charge or 11,000 lb (5000 kg) per hour on continuous charge
Heavy-duty 4” (100 mm) casters for full mobility
Dual brakes keep unit locked into place during use
Industrial grade hot-dip galvanized steel frame and cradle with zinc-plated wire mesh guarding
Weather-tight control panel control panel with key switch and digital battery indicator
Key switch controls access, while a digital battery indicator provides power visibility
Compact design limits total footprint
Operator guard cage and an interlocking safety door protect users
Suitable for indoor or outdoor use

Specifications

MODEL	TIP HEIGHT	CAPACITY	POWER SOURCE *	OVERALL LENGTH	OVERALL WIDTH	OVERALL HEIGHT	WEIGHT	IP RATING	SAFETY RATING
DM0700	27.5" (700 mm)	550 lb * (250 kg)	Battery ^† 3-Phase ^‡	46” (1175 mm)	38” (965 mm)	69” (1770 mm)	≈ 353 lb (≈ 160 kg)	IP56 *	CAT11/PLc
* Upgradable Specification † Battery powerpack, 24V/20Ah GEL (3hr charge on 100-264VAC 1-ph 50/60Hz ≤ 3A); unit includes sealed battery and industrial quality ‘float’ charger ‡ 3-Phase Mains powerpack, ≈ 415VAC 3-ph 50/60Hz ≤3.6A

MODEL

TIP HEIGHT

CAPACITY

POWER SOURCE *

OVERALL LENGTH

OVERALL WIDTH

OVERALL HEIGHT

WEIGHT

IP RATING

SAFETY RATING

DM0700

27.5"
(700 mm)

550 lb *
(250 kg)

Battery ^†

3-Phase ^‡

46”
(1175 mm)

38”
(965 mm)

69”
(1770 mm)

≈ 353 lb
(≈ 160 kg)

IP56 *

CAT11/PLc

* Upgradable Specification

† Battery powerpack, 24V/20Ah GEL (3hr charge on 100-264VAC 1-ph 50/60Hz ≤ 3A); unit includes sealed battery and industrial quality ‘float’ charger

‡ 3-Phase Mains powerpack, ≈ 415VAC 3-ph 50/60Hz ≤3.6A

Options

Auto-Cycle Operation
Available for mains-powered bin dumpers to enable operators to leave the machine to complete the cycle unattended.

Bin Hooks
Secure the dumper to a bin or skip with two adjustable hooks.

Bolt Down Kit
Secure the dumper with four galvanized steel lugs for permanent installation.

Compressed-Air Power
For use in hazardous areas.

Custom Controls
Operator controls can be mounted anywhere on the machine or remotely to suit productivity or safety requirements. Dual-hand controls are also available to prevent the operator from engaging in other interactions.

Custom Designs
Contact us with your specific requirements.

Digital Scales
Platform scales fit under cradle, allowing product to be weighed before dumping.

Right-Hinged Door
On standard Dockmaster models the door is hinged on the left-hand side, but can be hinged on the right if specified at the time of ordering.

Operator Guard
Unbreakable plastic guarding can be fitted adjacent to operator controls for protection when dumping liquids or harmful materials.

Polycarbonate (PET-G) Guarding
Unbreakable plastic guarding panels are available in place of the standard 1” x 1” (25 mm x 25 mm) wire mesh cage.

Safety Standards
Bin dumpers can be specified to meet international standards and/or CE regulations for an additional cost, depending on environment, application, and other factors.

Solar Panel (Battery-powered units only)
Battery-powered bin dumpers being used outside can be fitted with a solar panel. Depending on the amount of direct sunlight available, up to two tons can be emptied per day using solar power alone.

Stainless-Steel Construction
Bin dumpers are available either partially or completely constructed from high-grade 304 stainless-steel, suitable for hygiene-critical or corrosive environments such as food production or chemical processing. Corrosion-resistant lifting chains and fittings are also available.

Steel Bucket Cradle
Powder coated steel bucket cradle includes adjustable hoop retainer and adjustable packer blocks. Bolted to the main tote cradle plates, the Bucket Cradle accommodates all tubs that fit within 27” wide (686 mm), 24” deep (609.5 mm), 47” high (1194 mm), including all standard steel drums and BRUTE® Bins.

Swing-Up Locking Door
Instead of the standard side-hinged door, opt for the swing-up door, supported by gas struts and protected by a solenoid operated lock. The door is locked while a bin is lifted or lowered, and the machine cannot run while the door is open.

Tipping Chute
Frame-mounted tipping chute is available for situations where the machine cannot be flush with the bin or hopper. Note: the tipping height may need to be increased to accommodate the slope of the chute.
